APsmart RSD EYE+ Rapid Shutdown Signal Detector

The APsmart RSD EYE+ (RSD EYE+) is a handheld Smart Signal Detector built to sense PLC signal compliance to the SunSpec Alliance Rapid Shutdown Protocol. Designed for solar installers and service technicians, it operates at 9 VDC and 0.1 A across a wide -40°C to +60°C ambient range, letting crews confirm rapid shutdown signalling directly in the field. Compact and lightweight, it ships with red and black signal cables for quick connection.

Key Features:

• Handheld detection of SunSpec rapid shutdown PLC signal
• Smart Signal Detector for balance-of-system monitoring
• Input voltage 9 VDC, current 0.1 A
• Operating temperature -40°C to +60°C
• Enclosure rating IP20
• Sends in-line keep-alive signal to RSD
• Includes 30cm black and red signal cables
• Dimensions 5.4 x 1.7 x 1.0 in, 8.5 lbs
• 1 Year warranty

Ideal for installers and maintenance technicians commissioning or troubleshooting APsmart rapid shutdown systems. The included signal cables and optional external DC cable let crews verify SunSpec protocol compliance and send keep-alive signals to connected RSD devices quickly on site. Order the RSD EYE+ from Circuit Solar, in stock in Canada and shipped from Red Deer, AB.
