SolarEdge Home Wave 6kW Single Phase Inverter
The SolarEdge SE6000H-US000BEU4 Home Wave SE6000H is a 6kW single-phase grid-tie inverter delivering 99.2% peak efficiency (99% CEC) with a NEMA 4X enclosure for outdoor installation. It provides 6000 VA rated AC output at 240 VAC with 25 A maximum continuous current, integrated rapid shutdown, and built-in communication for reliable, code-compliant residential solar.
$2,217.00
Available to ship 44 ready to ship
Ships in 1–3 business days.
Delivers in 2–5 business days
Available for pickup
Brought in to Red Deer, AB when you order.
Pickup as early as Mon, Oct 19
— we’ll tell you about drops and promotions.
The SolarEdge SE6000H-US000BEU4 Home Wave SE6000H is a 6000W single-phase grid-tie inverter built for residential solar systems. It delivers 6000 VA of rated AC power at 240 VAC with a peak efficiency of 99.2% (99% CEC) and handles up to 9300 W of DC input. Transformer-less and ungrounded, it ships in a NEMA 4X enclosure rated for -40°F to 140°F operation, making it well suited to demanding Canadian climates.
Key Features:
- 6 kW rated output, 6000 VA at 240 VAC
- 99.2% efficiency, 99% CEC weighted
- Max DC power 9300 W, 480 VDC max PV input
- Max input current 16.5 A, short circuit 45 Adc
- 25 A max continuous output current at 240V
- AC output range 211 – 240 – 264 Vac, 59.3-60.5 Hz
- NEMA 4X enclosure, -40°F to 140°F operating
- Ethernet, RS485, WiFi, ZigBee communication
- Automatic rapid shutdown on AC grid disconnect
- 21.06 x 14.6 x 8.2 in, 262 lbs, 12-year warranty
Ideal for grid-tied residential rooftop systems, the SE6000H suits homeowners and installers needing code-compliant power conversion with integrated rapid shutdown. It commissions through the SolarEdge SetApp mobile application over built-in Wi-Fi and supports optional revenue-grade metering, consumption metering, and expanded communication interfaces. Order the SE6000H-US000BEU4 (also listed as SE6000HUS000BEU4) from Circuit Solar, in stock in Canada and shipped from Red Deer, AB.
